Polycarbonate(PC) Deflashing Media;Cryogenic Blast Media; Cryogenic
Deflashing Media; Polycarbonate Blast Media.
DEEP-COLD TECHNOLOGICS; ICE - COLD;
To run a cryogenic deflashing/deburring machine, liquid nitrogen,
and deflashing media are both required.
The media can be cyclic utilization.
We provide media testing for our deflashing/deburring machines.
Normally, following media sizes for options when treated with
different materials and different sizes of products, we provide
technical parameter guidance for each of your unique products.
| MEDIA SIZES | inches (LxW) | mm (LxW) |
| KG 40 | .015" x .015" | .40 x .40 |
| KG 050 | .020" x .020" | .50 x .50 |
| KG 075 | .030" x .030" | .75 x .75 |
| KG 100 | .038" x .038" | 1.0 x 1.0 |
| KG 120 | .045" x .045" | 1.2 x 1.2 |
| KG 150 | .060" x.060" | 1.5 x 1.5 |
| KG 200 | .080" x .080" | 2.0 x 2.0 |
Deflashing Media made/supplied by these companies is also possible
to be used on our cryogenic deflashing machines.
Any testing is welcomed by us.
Technical Parameters of Inter-China Cryogenic Deflashing Machine ;
| Main Data | Model | SD-A/AT | SD-M/MT | SD-L/LT |
SD-XL/XLT |
| Maximum Basket Volume(Litres) | 70 | 120 | 180 | 245 |
| Usable Volume (Litres) | 30~45 | 50~75 | 80~115 | 120~155 |
| Total Power (kW) | 5 | 7 | 9 | 13 |
| Refrigerant | Liquid Nitrogen (LN 2 ) |
| Operation Temp ( Degree) | 50 ~ -130 |
| Media Type | Polycarbonate |
| Power(voltage) | Three phase /AC380V±5% |
| Frequency(HZ) | 50/60 | 50/60 | 50/60 | 50/60 |
| Main Structure & Components | Control Mode | BUTTON/HMI | BUTTON/HMI | BUTTON/HMI | PLC&HMI |
| With alarm sensors to protect operators' safety |
| IMPELLER UNIT | Standard | Standard | Standard | Double System |
| Max Speed (rpm): ~7200 |
| Media Throwing Wheel Dia. (mm) |
| 250 | 300 | 300/350 | 300 |
| Sorting Device | Tunable Vibration Separator ( 3 Layers) |
| Material of Body & Inner Parts | SUS304 /Thermal Insulation Material (PIR )/Soundproof cotton |
| |
| Packing Infos | Equipment Weight(KG) | 1000 | 1300 | 1450 | 1600 |
| Equipment Size(cm) | 100*120*195 | 120*130*200 | 145*150*200 | 160*150*200 |
| | | | | | |
The average cycle time can range from 1.5 – 10 minutes depending on
the number of parts per batch (which is, dependent on the size of your molded parts); flash
thickness; wheel speed; and size of media used.
We have 4 standard models to meet different production demands;
The big capacity of the Basket is unique, which dual brings users
totally amazing productivity.
Order Options :
Capacity of Basket
Size of Impeller ( According to product size)
Color of Machine
Control Mode: Button or HMI
Tags:
auto parts blast boat hulls boat hulls boats catwalks cleaning fire
damage cleaning generators cleaning power generators clean
transformers co2 blasting co2 cleaning cryogenic cryogenically
treated steel cryogenic deburring cryogenic deflashing cryogenic
institute cryogenic treatment Cryogenic Tumbling cryo racing cryo
treat speaker wire Deburring deburring implants deburring nylon
deburring peek deburring plastic Deburring Proof of Concept
Deflashing deflashing equipment Deflashing Proof of Concept
deflashing silicone deflash rubber parts drill bits dry ice blast
cleaning Dry Ice Blasting Facebook furnace gas turbines LEED
certification nitro-freeze nitro freeze deburring Nitrofreeze
Deflashing paper mill plastic flash removal silicone deflashing
Teflon deburring
For more details, please get in touch with us freely !!!
